RST 599TK

This app is a real CW QSO simulator for Amateur Radio.

599BK & AADX Contest type QSO is supported.

Input of Morse Codes are by using Electric Touch Keyer.

Changing of TX/RX is by SEND button.

Supported Min-in CW Decoder too.

Characteristic

1.
599BK and Contest style support.

2.Support the CW Speed Control, Reverse of Dot/Dash pad.

3.Status display showing TX / RX operation.

4.Support the space insertion operation both automatic and manual.

5.Support the Min-in CW Decoder function.

6.Support the shortcut-key of CQ and TU.

CQ Button function can be set by setting menu.

7.Support the repeat-call function.

It works only when the TU button is pressed at the end of the QSO.

8.Support input function by key button

How to use

1.The case of CQ Calling

Press SEND button

Input CQ CQ DX DE (YOUR CALLSIGN) PSE K by Touch Keyer.

Press SEND button again

2.The case of CQ Answering

Press SEND button

Input QRZ DX by Touch Keyer or Straight Key.

Press SEND button again

--- Examples of QSO ---

[CQ Calling]

CQ CQ DX DE xxnxx xxnxx PSE K

>>> xxnxx DE **n** K

**n** DE xxnxx UR RST 559 BK

>>> R MY RPT 559 UR RST 599 BK

QSL TU

>>> R 73 TU

E E

>>> E E

[CQ Ansewing]

QRZ DX

>>> CQ CQ DE **n** **n** PSE K

**n** DE xxnxx K

>>> xxnxx DE **n** UR RST 579 BK

R **n** DE xxnxx UR RST 599 TU

>>> R TU

E E

>>> E E

--- DETEC WORDS ---

[CQ Calling]

CQ

CQ DX

CQ NA

CQ JA

[CQ Ansewing]

QRZ

QRZ DX

QRZ NA

QRZ JA

[BOTH]

DE

K

BK

UR RST

73

TU

E E

etc.

Example usage video

- Touch Keyer -

https: //www.youtube.com/watch?v=CuSEaJtD3KQ

- Microphone IN Mode -

https: //www.youtube.com/watch?v=goN9hVDEGnM,
