Temperature&Humidity Data logger

The GSM SMS GPRS 3G 4G Temperature &Humidity Monitoring Alarm embedded GSM/GPRS/3G/4G module and high performance MCU to provide an all in one instrument for data logging, Remote data acquisition, alarm and control.
It special for real-time remotely monitoring onsite temperature, humidity, power status and automatically switch on/off equipments through wireless cellular network.

It provides 4/8 temperature &humidity probe inputs or 8 high precision temperature probe inputs.
When the temperature, humidity exceed high threshold or low threshold value, or external power goes off or on, will send SMS alert to 10 preset mobile phone immediately or upload event data to remote server by GPRS/3G/4G network.

It provides daily report, schedule upload, event upload by the GPRS/3G/4G to monitoring center or by SMS to the user mobile phone directly.

The Data Logger with large memory that can save 200000 events.
It provides 2 Relay outputs for automatically switch ON/OFF devices when Temperature & Humidity exceed high/low value and remote switch ON/OFF Device by SMS or GPRS/3G/4G networks.

It has been designed as a cost effective, low power, easy use, reliable data logger.
It can be used in the worldwide through the wireless cellular network, operation in anywhere, no distance limitation.,
